这里简单演示一下Apache下基于加密的认证访问----https加密方式访问。
1.DNS解析解析情况：
[root@localhost html]# nslookup www.aizhanzhe.com Server: 192.168.2.115 Address: 192.168.2.115#53 Name: www.aizhanzhe.com Address: 192.168.2.115
2.安装Apache SSL支持模块:# yum install -y mod_ssl （默认yum安装httpd是没有安装该模块的，安装后自动生产/etc/httpd/conf.d/ssl.conf文件）并生成证书。
[root@localhost certs]# pwd /etc/pki/tls/certs [root@localhost certs]# ls ca-bundle.crt index.html localhost.crt Makefile ca-bundle.trust.crt localhost1.crt make-dummy-cert [root@localhost certs]# openssl req -utf8 -new -key ../private/localhost.key -x509 -days 3650 -out abc_com.crt You are about to be asked to enter information that will be incorporated into your certificate request. What you are about to enter is what is called a Distinguished Name or a DN. There are quite a few fields but you can leave some blank For some fields there will be a default value, If you enter '.', the field will be left blank. ----- Country Name (2 letter code) [XX]:CN State or Province Name (full name) []:510510 Locality Name (eg, city) [Default City]:GZ Organization Name (eg, company) [Default Company Ltd]:ABC.COM Organizational Unit Name (eg, section) []:Mr.Zhang Common Name (eg, your name or your server's hostname) []:www.downcc.com Email Address []:root@abc.com [root@localhost certs]#
3.配置Apache，基本配置这里不多说了，下面是配置www.aizhanzhe.com站点http访问的情况。
[root@localhost html]# tail -n 8 /etc/httpd/conf/httpd.conf NameVirtualhost 192.168.2.115:80 <VirtualHost www.aizhanzhe.com:80> ServerAdmin webmaster@dummy-host.example.com DocumentRoot /var/www/html ServerName www.aizhanzhe.com ErrorLog logs/dummy-host.example.com-error_log CustomLog logs/dummy-host.example.com-access_log common </VirtualHost> [root@localhost html]# tail /var/www/html/index.html www.aizhanzhe.com [root@localhost html]#
4.配置Apache支持https访问www.aizhanzhe.com站点，编辑 vim /etc/httpd/conf.d/ssl.conf 文件，制定www.downcc.com站点https访问时的相关信息。添加下面配置。
<VirtualHost www.aizhanzhe.com:443>
DocumentRoot "/var/www/html/www.kuteatest.net" #//为了显示效果，这里的站点目录不一样，一般情况一个域名应该指向同一目录的。ServerName www.downcc.com:443
ErrorLog logs/ssl_error_log
TransferLog logs/ssl_access_log
LogLevel warn
SSLEngine on
SSLProtocol all -SSLv2
SSLCipherSuite ALL:!ADH:!EXPORT:!SSLv2:RC4+RSA:+HIGH:+MEDIUM:+LOW
SSLCertificateFile /etc/pki/tls/certs/abc_com.crt
SSLCertificateKeyFile /etc/pki/tls/private/localhost.key
<Files ~ "\.(cgi|shtml|phtml|php3?)$">
SSLOptions +StdEnvVars
</Files>
<Directory "/var/www/cgi-bin">
SSLOptions +StdEnvVars
</Directory>
SetEnvIf User-Agent ".*MSIE.*" \
nokeepalive ssl-unclean-shutdown \
downgrade-1.0 force-response-1.0
CustomLog logs/ssl_request_log \
"%t %h %{SSL_PROTOCOL}x %{SSL_CIPHER}x \"%r\" %b"
</VirtualHost>5.重启Apache服务，测试访问。
测试http访问的结果
测试https访问的结果
查看证书信息和自建crt信息一致
https访问的最终结果
